| NICKEL PHTHALOCYANINE Basic information |
| Product Name: | NICKEL PHTHALOCYANINE | | Synonyms: | (Phthalocyaninato(2-))nickel;[29H,31H-phthalocyaninato(2-)-N29,N30,N31,N32]-,(SP-4-1)-Nickel;2,1-Phthalocyaninato nickel;2,1-Phthalocyaninatonickel;31h-phthalocyaninato(2-)-n29,n39,n31,n32]-[29(sp-4-1)-nicke;Nickel phthalocyanine blue;Nickel, (phthalocyaninato(2-))-;Nickel, [29H,31H-phthalocyaninato(2-)-N(29)-,N(30)-,N(31)-,N(32)-]-, (SP-4-1)- | | CAS: | 14055-02-8 | | MF: | C32H16N8Ni | | MW: | 571.22 | | EINECS: | 237-893-3 | | Product Categories: | Organometallics;OLED;phthalocyanines | | Mol File: | 14055-02-8.mol |
| NICKEL PHTHALOCYANINE Chemical Properties |
| NICKEL PHTHALOCYANINE Usage And Synthesis |
| Chemical Properties | very dark blue crystalline powder | | Purification Methods | Wash it well with H2O and boiling EtOH and sublime it at high vacuum in a slow stream of CO2. A special apparatus is used (see reference), with the phthallocyanine being heated to red heat. The sublimate is in the form of needles with an extremely bright red lustre. The powder is dull greenish blue in colour. [Barrett et al. J Chem Soc 1719 1936, Beilstein 26 III/IV 4255.] |
| NICKEL PHTHALOCYANINE Preparation Products And Raw materials |
|
