| Ru(4,4-dicarboxylic acid-2,2′-bipyridine)(4,4′-bis(p-hexyloxystyryl)-2,2-bipyridine)(NCS)2 Basic information |
| Ru(4,4-dicarboxylic acid-2,2′-bipyridine)(4,4′-bis(p-hexyloxystyryl)-2,2-bipyridine)(NCS)2 Chemical Properties |
| Melting point | >300°C | | form | powder (black) | | Odor | Dark brown powder |
| Hazard Codes | Xi | | Risk Statements | 36/37/38-43 | | Safety Statements | 26 | | WGK Germany | 3 |
| Ru(4,4-dicarboxylic acid-2,2′-bipyridine)(4,4′-bis(p-hexyloxystyryl)-2,2-bipyridine)(NCS)2 Usage And Synthesis |
| Description | Cis-bis(thiocyanato)(2,2'-bipyridyl-4,4'-dicarboxylic acid)(4,4'-bis(phexyloxystyryl)-2,2'-bipyridine)ruthenium(II), K19 Dye sensitizer, is ruthenium complex dye developed for high-efficiency dye-sensitized solar cells (DSSC).?High extinction coefficient (18200 M-1cm-1) of K19 sensitizer enables realisation of a new generation thin-film dye-sensitized solar cells (DSCs) yielding higher conversion efficiency [1, 2]. | | Uses | K19 Dye is an organo-metallic dye that can be used as a photosensitizing material in the fabrication of dye sensitized solar cells (DSSCs). It shows a short circuit photocurrent density of 15.1 mA/cm2, an open circuit voltage of 747 mV and a fill factor of 0.69. | | General Description | K19 Dye is an amphiphilic ruthenium sensitizer with a good molar extinction coefficient, which remains stable under thermal stress and light soaking. It can be synthesized by forming a reaction mixture of 4,4′-Bis(p-hexyloxystyryl)-2,2′-bipyridine, dichloro(p-cymene)ruthenium(II) dimer, and 4,4′-dicarboxylic acid-2,2′-bipyridine. It shows an overall power conversion efficiency (PCE) of 11% and can be used as an active material in electrochemical applications. |
| Ru(4,4-dicarboxylic acid-2,2′-bipyridine)(4,4′-bis(p-hexyloxystyryl)-2,2-bipyridine)(NCS)2 Preparation Products And Raw materials |
|
