Other grades of this product :
| (6,6)-PHENYL C71 BUTYRIC ACID METHYL ESTER, 99% (MIXTURE OF ISOMERS) Basic information | | Applications |
| Product Name: | (6,6)-PHENYL C71 BUTYRIC ACID METHYL ESTER, 99% (MIXTURE OF ISOMERS) | | Synonyms: | Methyl [6,6]-Phenyl-C71-butyrate;(6,6)-Phenyl C71 Butyric Methyl Ester, [60]PCBM;(6,6)-PHENYL C71 BUTYRIC ACID METHYL ESTER, [70]PCBM;PCBM(C70) 5G;(6,6)-PHENYL C71 BUTYRIC ACID METHYL ESTER, 99% (MIXTURE OF ISOMERS);[6,6]-Phenyl C71 butyric acid methyl ester, mixture of isomers;[70]PCBM, 3μH-Cyclopropa[8,25] [5,6]fullerene-C70-D5h(6)-3μbutanoic acid, 3μPhenyl-3μH-cyclopropa[8,25] [5,6]fullerene-C70-D5h(6)-3μbutanoic acid, methyl ester;PCBM(C70) | | CAS: | 609771-63-3 | | MF: | C82H14O2 | | MW: | 1031.01 | | EINECS: | | Product Categories: | OLED;OTFT/OFET/OPV Materials | | Mol File: | 609771-63-3.mol |
| (6,6)-PHENYL C71 BUTYRIC ACID METHYL ESTER, 99% (MIXTURE OF ISOMERS) Chemical Properties |
| Hazard Codes | Xi | | Risk Statements | 36/37/38 | | Safety Statements | 26 | | WGK Germany | 3 | | HS Code | 29163990 |
| (6,6)-PHENYL C71 BUTYRIC ACID METHYL ESTER, 99% (MIXTURE OF ISOMERS) Usage And Synthesis |
| Applications | PC70BM is a fullerene electron acceptor commonly used in the most efficient organic photovoltaic devices. The non-symmetrical C70 cage of PC70BM enables energetic transitions that are forbidden in C60, improving the absorption characteristics over PC60BM for the visible range of the solar spectrum. This allows increased photon harvesting, and a potentially higher photocurrent for devices using PC70BM rather than PC60BM. The 95% purity PC70BM is recommended for general applications, and has produced power conversion efficiencies of over 9% in our own laboratories when mixed with a low bandgap polymeric donor, while the 99% PC70BM is recommended where ultimate performance is required.
The energy levels and good electron mobility of PC70BM enable it to be used as an electron transport layer in perovskite solar cells. In our laboratories, we have achieved a PCE approaching 12% using PC70BM in CH3NH3PbI3-xClx perovskite solar cells.
| | Description | PC70BM is a fullerene electron acceptor commonly used in the most efficient organic photovoltaic devices. The non-symmetrical C70 cage of PC70BM enables energetic transitions that are forbidden in C60, improving the absorption characteristics over PC60BM for the visible range of the solar spectrum . This allows increased photon harvesting, and a potentially higher photocurrent for devices using PC70BM rather than PC60BM.?The 95% purity PC70BM is recommended for general applications, and has produced power conversion efficiencies of over 9% in our own laboratories when mixed with a low bandgap polymeric donor,?while the 99% PC70BM is recommended where ultimate performance is required. | | Chemical Properties | Light brown to black solid | | Uses | [70]PCBM can be blended with a variety of electron donors, which include P3HT and MDMO-PPV, for the fabrication of polymeric solar cells with a high power conversion efficiency (PCE). It can also be used in the organic field effect transistor (OFET) based applications. | | General Description | [6,6]-Phenyl C71?butyric acid methyl ester, mixture of isomers ([70]PCBM), is a high fullerene analog to [60]PCBM, which has an enhanced absorption of light in the visible region. It can be used in the development of electrochemical devices with a high current density. |
| (6,6)-PHENYL C71 BUTYRIC ACID METHYL ESTER, 99% (MIXTURE OF ISOMERS) Preparation Products And Raw materials |
|
